Product Description:
Material Properties
The primary materials used in mainstream products are thermoplastic elastomer (TPE). However, other materials such as EPDM (Ethylene Propylene Diene Monomer) rubber and Viton (fluororubber) are available upon request to suit specific needs. TPE is favored for its excellent tensile strength even without fabric reinforcement and is manufactured through precision injection molding.
This material offers remarkable flexibility, enabling products to withstand frequent opening and closing cycles while maintaining dependable sealing performance. Additionally, TPE is cost-effective, making it ideal for a wide range of industrial dust removal applications. In contrast, EPDM and Viton are tailored to fulfill demands of harsh environments, including high temperatures and exposure to corrosive substances.
Furthermore, certain maintenance kits are equipped with both primary and secondary diaphragms to enhance sealing reliability and operational stability.
Operating Parameter Properties
The products are designed to operate efficiently within a pressure range of 0.4 to 8 bar, corresponding to the typical pulse valve operating pressures. This range supports stable opening and closing actions, ensuring the pulsed airflow effectively dislodges dust from filter bags.
In terms of temperature resilience, these materials can tolerate medium temperatures from -40℃ up to +85℃, as well as ambient temperatures ranging between -20℃ and +85℃. Such adaptability allows the products to function reliably under fluctuating high and low temperatures typical in industrial environments, without the risk of brittleness or deformation.
Thanks to high-quality TPE and advanced manufacturing techniques, the service life of these components can reach up to one million operational cycles. This durability considerably minimizes the need for frequent maintenance and replacements.
Functional and Performance Properties
Serving as the sole moving part within the pulse valve, these components perform rapid opening and closing motions that produce shock air waves. These waves effectively shake dust loose from filter bags, ensuring thorough cleaning. The design also supports high flow rates, which contributes to the operational efficiency and prompt response of the pulse valve, making its operation both economical and reliable.
The sealing capabilities of TPE are outstanding, and when combined with the diaphragm’s structural design, they prevent gas leakage effectively. Moreover, the materials exhibit a degree of resistance to contamination, thereby reducing the negative effects of impurities on sealing performance.
Some exhaust structures incorporate threaded interfaces that help limit the ingress of impurities, which indirectly extends the diaphragm’s lifespan by maintaining its sealing integrity.
Technical Parameters:
| Medium |
Compressed air |
| Operating Pressure |
0.4 ... 8 bar, 6 ... 116 psi |
| Port Size |
G1-1/2 |
| Coil Code |
8171 |
| Function |
NC |
| Nominal Diameter |
40 mm |
| Valve operation |
2/2 |
| CV Body |
68 cv |
| Materials - Body |
Aluminium |
| Materials - Elastomers |
Thermoplastic Elastomer (TPE) |
| Certification - IP Rating |
IP65 |
| Dimensions - Height |
135 mm |
| Dimensions - Length |
125 mm |
| Dimensions - Width |
160 mm |
| Weight |
1.2 kg |
| Country of Origin |
Germany |
| Range |
82960 |
| Brand |
IMI Buschjost |
|
Applications:
The Taeha Pulse Valve Diaphragm, model number 1261253, is an essential component designed specifically for pulse jet valves with a size fitted for a 3/4'' pulse valve port. Crafted with high-quality nylon as the seat material, this diaphragm ensures durability and reliable performance in various industrial applications. Certified with CE standards, the Taeha Pulse Valve Diaphragm meets strict quality and safety requirements, making it a trusted choice for maintenance and replacement needs.
This product is widely used as part of a Maintenance Kit for pulse jet valves, which are critical in dust collector systems, pneumatic conveying, and air filtration equipment. The diaphragm plays a vital role in controlling the release of compressed air pulses that clean dust and particulate matter from filter bags or cartridges, ensuring optimal operation and longevity of the filtration system. Regular replacement of the diaphragm as part of scheduled maintenance kits helps prevent valve malfunctions, reduces downtime, and maintains system efficiency.
Pulse jet valves equipped with the Taeha diaphragm are commonly found in industries such as cement production, power generation, chemical processing, and food manufacturing, where dust control and air purification are paramount. The diaphragm's robust nylon seat material provides excellent resistance to wear and tear, even in harsh operating environments with fluctuating temperatures and pressures.
With a minimum order quantity of just one piece, Taeha offers flexibility for both small-scale repairs and large-scale maintenance operations. The product is packaged securely in cartons to ensure safe delivery, with a fast turnaround time of 1-7 workdays after payment. Payment terms include T/T, Western Union, and PayPal, accommodating various buyer preferences. Taeha’s supply ability of up to 5000 pieces per month guarantees availability for ongoing maintenance programs.
Whether you are sourcing a reliable replacement diaphragm for your pulse jet valve maintenance kit or looking to maintain optimal performance in your dust collection systems, the Taeha Pulse Valve Diaphragm is an excellent choice. Its certification, quality materials, and efficient delivery make it a valuable component for ensuring the longevity and functionality of pulse jet valves across many industrial applications.
